CBB60 AC Metallized Polypropylene Motor Run Capacitor

  1. Round-shape plastic or metal case,insulating cap,plastic cap or expoxy resin sealed.

  2. Lug type,wire type or cable type;with the bolt and nut or not;or designedand made according to customer's special requests .

  3. Low dissipation factor,high insulation resistance,good self-healing,stable performance,good ability of resisting impact current and overload .

  4. Suitable for washing machine and detached hors-power motor,pump and beneficial to the starting and running of AC motor.





Technical Date :



Ambient temperature-40—+85°c
Rated Voltage250—500VAC
Capacitance  Range1-100µF
Test VoltageT-T: 2Un/2s T-C: 2200VAC/2s
Capacitance  Tolerance±5%,±10%
Dissipation Factortg0.002(100Hz, 20°c)
Operating Frequency50/60HZ
Executing StandardIEC60652,UL810,EN60252,VDE0560-8,GB/T3667.1-2005









 Details:

CBB60
ModelSize
CBB60/450V1.5UF34*60
2UF34*60
2.5UF34*60
4UF34*60
5UF34*60
6UF34*60
8UF34*70
10UF34*70
12UF38*70
14UF38*70
16UF38*70
18UF42*70
20UF42*70
22UF42*70
24UF42*90
25UF42*95
30UF45*95
35UF45*95
40UF45*95
45UF50*90
50UF50*100
55UF50*120
60UF50*120
70UF55*120
80UF55*120
85UF55*120
100UF60*120
12OUF60*120
CBB60/370V20UF40*70
22UF42*70
24UF42*70
25UF42*70
30UF45*90
35UF45*90
40UF45*90
45UF45*95
50UF50*90
55UF50*95
60UF55*120
70UF55*120
1.5UF34*60
2UF34*60
2.5UF34*60
4UF34*60
5UF34*60
6UF34*60
8UF34*70
10UF34*70
12UF38*70
14UF38*70
16UF38*70
18UF40*70
CBB60 with cable40UF/300V50*115
Washmachine52UF/300V50*115
